S-Series Source Measure Unit

Precise Instrument Co.,Ltd has been creating S series source measure unit for so many years.The source measure unit is similar to keithley smu 2400 2401 2450 which has high-precision,large dynamic range,digital touch screen, four-quadrant operation,collect and test input & output voltage and current,meanwhile, maximum output voltage 300V,and minimum output current 100pA.Therefore,it is widely used in electrical characteristics like I-V curve tests.

Add Your Heading Text Here

OUR PRODUCTS FEATURES

Why Choose S-Series Source Measure Instruments?

Powerful performance-Synchronous sourcing and measuring

As a voltage source and or current source, and simultaneously measure current and or voltage, support four-quadrant work. The voltage or current output can be limited to prevent device damage. Covering the current range of 3 pA – 3 A and the voltage range of 100μV-300V, the full-scale measurement accuracy is 0.03%.

Flexible and diverse

Support two-wire and four-wire measurement, more accurate low internal resistance measurement; integrated linear ladder scan, logarithmic ladder scan, custom scan, and other modes; professional I-V characteristics and semiconductor parameter testing software.

Easy to learn and use

Simplifies measurement preparation for various applications such as I-V and I-t/V-t curves. The capacitive touchscreen graphical user interface (GUI) provides two display modes of graphical and digital measurement results, which are easy to use and view.

All-in-one High-Precision SMU, Extremely Simplified Measurement

Traditional semiconductor I-V characteristic measurement solutions are usually complex and costly, requiring a variety of instruments to complete the test, programming, synchronization, connection, measurement and analysis of different instruments, which is complex, time-consuming, and takes up a lot of test bench space The S series digital source measure unit can be used as an independent constant voltage source or constant current source, voltmeter, ammeter and ohmmeter, and can also be used as a precision electronic load. Its high-performance architecture allows it to be used as a waveform generator, and automatic current-voltage (I–V) Characterization system. Greatly shorten the development, establishment and maintenance time of the test system, save valuable “space” of the test rack or test bench at the same time, and reduce the overall cost of purchasing the test system.

User-Friendly Multi-Touch Operation and Connection

The S-Series Source measure Unit (SMU) features an easy-to-use front panel design and intuitive operability based on PRECISE’s 15 years of user experience. The intuitive user interface is recognized and favored by users in fields such as R&D and manufacturing test

5 inch Touch Screen graphical operation
Wide range Max 300V,Min 10pA,maximum test power is 30W
LIV, PIV software quickly testing
High-accuracy at 0.1% Various scanning modes
Four-quadrant operation 100nA~1A, 300mV~300V
USB storage and export
Multiple interfaces RS-232/GPIB/LAN
Can be used to test the electrical performance indicators of semiconductors: I, V, R
