Accessories

Home > Products > Accessories

Sl. No.

PRODUCT IMAGE

MODEL NO

PRODUCT DESCRIPTION

PRICE

PASSIVE PROBE

1 RIGOL RP1018H OSCILLOSCOPE 150 MHZ PASSIVE HIGH VOLTAGE PROBE

High Voltage Probe with 150MHz bandwidth, 18kV max DC voltage, 1000:1

• Bandwidth: DC ~ 150MHz
• Damping factor: 1000: 1
• Input resistance: 200MO
• Input capacity: 1,5pF
• Maximum input voltage: DC + AC peak: 18kV CAT II; AC RMS CAT II 12kV
• Maximum current: 90µA
• Compensation range: 10pF ~ 35pF

2 RIGOL RP1010H OSCILLOSCOPE 40 MHZ PASSIVE HIGH VOLTAGE PROBE

High Voltage Probe with 40MHz bandwidth, 10kV max DC voltage, 1000:1

• Bandwidth: DC ~ 40MHz
• Damping factor: 1000: 1
• Input resistance: 100 MW ± 5%
• Input capacity: 3pF ± 0,5pF
• Maximum working voltage: DC: 0 ~ 10 kV; AC: = 20kVpp pulse; AC: sine wave = 7kVrms
• Compensation range: 5pF ~ 50pF

3 RIGOL PVP3150 – 150 MHZ PASSIVE PROBE WITH 1X:10X

150 MHz Passive Probe with 1x:10x selector. With bandwidth of 20 MHz in 1x mode

• 150 MHz Passive Probe
• Bandwidth of 20 MHz in 1x Mode
• Compensation Range: 10 pF to 25 pF
• Cable Length: 120 ± 2 cm
• Probe Tip Diameter: 4.8 mm

4 RIGOL PVP2350 (10:1)

High Z passive probe. Switchable.

• Input Impedance : 10 MΩ ± 2%
• Bandwidth : DC – 350 MHz
• Compensation Range : 6 pF – 24 pF
• Max. Input Voltage : CAT II 300 VAC
• Cable Length : 1.4 m

5 RIGOL RP5600A (1X)

High Z passive probe

• Input Impedance : 10 MΩ ± 2%
• Bandwidth : DC – 600 MHz
• Compensation Range : 6 pF – 26 pF
• Max. Input Voltage : CAT II 300 VAC
• Cable Length : 1.4 m

6 RIGOL RP3500A (1X)

High Z passive probe

• Input Impedance : 10 MΩ ± 2%
• Bandwidth : DC – 600 MHz
• Compensation Range : 6 pF – 26 pF
• Max. Input Voltage : CAT II 300 VAC
• Cable Length : 1.4 m

7 RIGOL RP1300H (100:1X) HIGH VOLTAGE PROBE

High Z passive high-voltage probe

• Input Impedance : 100 MΩ
• Bandwidth : 300 MHz
• Rise time : 1.2 ns
• Compensation Range : 10 pF – 35 pF
• Max. Input Voltage : CATI 2000 V (DC+AC), CATII 1500 V (DC+AC)
• Cable Length : 1.4 m

8 RIGOL RP6150A (1X)

Low Z passive probe

• Input Impedance : 500Ω ±10Ω
• Bandwidth : 1.5 GHz
• Max. Input Voltage : CAT I 7 VAC
• Cable Length : 1.4 m

9 RIGOL PVP2150 (10:1/1:1)

High Z passive probe

Specification 1 : 1 10 : 1
Input impedance 1 MΩ 2% 10 MΩ 2%
Bandwidth 7 MHz 150 MHz
Rise time 50 ns 2,3 ns
Compensation Range 5 pF – 29 pF 5 pF – 29 pF
Max. Input CAT II 150 V CAT II 300 V
Cable length 1,4 m 1,4 m

DIFFERENTIAL PROBE

10 RIGOL RP1100D DC-100 MHZ, 7000 VPP HIGH VOLTAGE DIFFERENTIAL PROBE

High Voltage Differential Probe, DC-100 MHz, 7000 Vpp

11 RIGOL RP1050D HIGH VOLTAGE DIFFERENTIAL PROBE, DC-50 MHZ, 7000 VPP

High Voltage Differential Probe DC-50 MHz 7000 Vpp

12 RIGOL RP1025D HIGH VOLTAGE DIFFERENTIAL PROBE, DC-25 MHZ, 1400 VPP

High Voltage Differential Probe DC-25 MHz 1400 Vpp

CURRENT PROBE

13 RIGOL CURRENT PROBE RP1001C

Current probe up to 100 A Peak and 300 kHz bandwidth.

14 RIGOL CURRENT PROBE RP1002C

15 RIGOL CURRENT PROBE RP1003C

Current probe up to 50 A Peak and 50 MHz bandwidth. Requires Rigol RP1000P or similar power adapter.

16 RIGOL CURRENT PROBE RP1004C

Current probe up to 50 A Peak and 100 MHz bandwidth. Requires Rigol RP1000P or similar power adapter.

17 RIGOL CURRENT PROBE RP1005C

Current probe up to 300 A Peak and 10 MHz bandwidth. Requires Rigol RP1000P or similar power adapter.

18 RIGOL CURRENT PROBE POWER SUPPLY RP1000P

Power adapter for up to four RP1003C, RP1004C and RP1005C Current Probes.

LOGIC PROBE

19 RIGOL RPL1116 LOGIC PROBE

Set of digital logic probes (RPL1116, 16 channel + 16 ground) for the MSO option of the Rigol DS1000Z-Plus series.

20 RIGOL RPL2316 LOGIC PROBE

Set of digital logic probes (RPL1116, 16 channel + 16 ground) for the MSO8000 series.

21 RIGOL PLA2216 ACTIVE LOGIC PROBE

Set of digital logic probes (PLA2216, 16 channel + 16 ground) for the Rigol MSO5000 series.

22 RIGOL NFP-3 NEAR-FIELD PROBE SET

Near Field Probe, Requency Range: 30MHz to 3GHz • Frequency Range: 30MHz to 3GHz • One set includes four types of probe, provides optimizing sensitivity and resolution • Minimum resolution: 2mm; able to capture near field radiation of single circuit line • Applicable for electromagnetic leakage testing inside the cable • A measurement tool for EMI pre-conformance testing, troubleshooting, and design verification • Determine frequency and relative intensity of the spectral components of the interference source • RF connection: SMB (male)

23 Rigol CK106E Calibration Kit

Vector Network Analysis Calibration kit for RSA N models. This kit enables RSA calibration from DC to 1.5 GHz.

24 Rigol CK106A Calibration Kit

Vector Network Analysis Calibration kit for RSA N models. This kit enables RSA calibration from DC to 6.5 GHz.
